FF-040GK015S

Marca	Honsberg
Prodotto	FF-040GK015S
Codice interno	PRT277527
Peso	1
Codice doganale	85365080
Specifiche tecniche	Article number: 957689 Description: Flow Switch Nominal diameter: DN 40 Connection: Female thread G 1½ Housing: Stainless steel Pressure resistance: PN 20 Internal parts: POM Seal: NBR Media temperature: -20 ... +90 °C Environmental temperature: -20 ... +70 °C Adjustment range: Volumetric flask SC Switching point: 1.5 l/min H2O decreasing off , 1.7 l/min increasing on Switching head: Stainless steel Electrical connection: Pg with 1.8 m cable Electrical contact: Reed switch Max. contact load: 230 V AC 1 A 50 VA Connection diagram: Normally-open contact, connection diagram no. 0.212 Protection type: IP65 Flow direction: Horizontal from the lef
