MI-DM0080 DM0803-ASL01B0L8HDJ-200mm

Marca	Interroll
Prodotto	MI-DM0080 DM0803-ASL01B0L8HDJ-200mm
Codice interno	PRT4452040
Specifiche tecniche	Product name DM 0080 asynchronous 3-phase Protection grade IP 69K Pipe length (SL) 193.0 mm Drum width (FW) 200.0 mm Installation length (EL/LW/BF) 205.0 mm Axis total length (AGL) 230.0 mm power 75 W Number of poles winding 2 Torque [Nm] 7.6 belt tensile force 174 N Gear ratio (i) 31.35 Transmission material designation steel: 16MnCr5/AISI 5115 velocity at frequency 1 0.39 m/s frequency 1 50 Hz external connection diagram M30 low voltage 230 V Rated current, low voltage 0.46A velocity at frequency 2 0.47 m/s frequency 2 60 Hz low voltage 2 230 V Pipe material stainless steel: 1.4301/304 Tube diameter (A) 87.5 mm Tube diameter (B) 86.5 mm Tubular shape crowned (standard) pipe option type smooth rubber coating coating material NBR rubber coating Coating hardness 70 shore A coating color white coating process hot vulcanized Lid A, standard design Lid B standard design Lid A Material ALU: EN-AC43400/AL239 Lid B Material ALU: EN-AC43400/AL239 Shaft A version standard Ø17mm Shaft B version standard Ø17mm Shaft A material stainless steel: 1.4305/303 Shaft B material stainless steel: 1.4305/303 Wave A final area size (F) 13.5 mm Shaft B final area width (F) 13.5 mm Shaft A final surface length (C) 12.5 mm Shaft B final surface length (C) 12.5 mm oil type synthetic food oil Electrical connection straight screw connection Elec. Connection material stainless steel: 1.4301/304 power cable length 5.0 m Power cable type shielded; not halogen free
