| Marca | Groschopp |
| Prodotto | Type IGKU 65-40 with SG80 i= 347:1 |
| Descrizione | MOTORIDUTTORE ASINCRONO AC |
| Codice interno | PRT4522494 |
| Specifiche tecniche | Type: IGKU 65-40, 380-440/220-254V, 50Hz 380-480/220-277V, 60Hz 0.11-0.13/0.19-0.23A 1220-1600U, 18W, B3, IP65, Motor wound according to WK 1699801, left-right rotation, circuit diagram S61-0701-24, motor UR/UL conform, phase isolation motor, motor with terminal box AK2, and 6-pin terminal board, circuit diagram in the terminal box, Motor with heat monitor 140°C as opener mounted with: SPUR GEAR Type: SG80/B3/B14 i= 347:1, 5-stage n2= 3.5 rpm, M2= 17.1 Nm Service factor fB= 0.47 Gear shaft Ø 10mm x 20mm long with groove+key 3x3x16 mm, Terminal box position: 42 Transmission mounting position: 1 design and dimensions Drawing 2009-07-000291 |
